Configuration Highlights

• Capacity (per minute in one direction) 2 x 22
• Standard unit size (W x H) 1600 x 2300 mm
• Standard dimensions 695 mm throat opening, 200 mm canopy height, three door wings
• LEVEL UP high 2100 - 3600 mm / canopy height 200 - 1200 mm
• LEVEL UP wide 1600 - 3800 mm, in increments of 200 mm
• Night locking Manual locking doorset
• LEVEL UP security External or internal shield doors, security lockdown, burglar protection
• Standard Fire alarm connection, vandal resistant, CE basic
• LEVEL UP safety BoonAssist speed control, burglar or bullet resistant protection packages
• Standard finish Powder Coated Aluminium
• LEVEL UP aesthetics Stainless steel, Anodic coating, Anodizing, Brass
• Drive Drive unit in canopy
• LEVEL UP technology BoonAssist with low energy drive unit
• LEVEL UP comfort Push-button temporary low speed, air curtains
• Request - BIM Objects and/or Technical Drawings
• Request - Tourniket Specification Text
• Tourniket | Brochure
• Touchless - Revolving Doors | Brochure
• Level Up | Brochure
• Safety Norm - EN16005 | Brochure
• 3 or 4-Wing configuration
• Rigid, collapsible or automatic folding doorset
• Manual, semi-automatic or fully automatic operation
• Large selection of dimensions
• BoonAssist: Low energy assisting and positioning
• Handles low to moderate throughput
• Access for all (easy, convenient disabled support)
• Automatic operation for touchless entry
• Highly customisable (extend your brand)
• Sustainable and energy-saving
• Draft-free entrance (Reduced air infiltration)
• BoonAssist: PPS - a control system that helps the user during pushing (power assisted), positions automatically to the rest position (positioning), and limits the speed during pushing (speed control)
• Accessibility buttons
• Contrasting stickers with safety icons on the door wings and curved walls
• Sensors with laser technology
• Block detection
• Emergency stop and / or open buttons
• CE plus package
• RC3 Burglar protection package
• Automated or manual locking options
• External automatic shield doors (night locking)
• Security lockdown for immediate action
• Access control options
• An available upgrade option with Remote Locking allows after-hours access through the revolving door via an input from an access control system (provided by others). Read more
• Need an entrance providing a high security level? Perhaps the Tourlock 180 is a better solution for you. Read more
• You need to accommodate a high footfall of pedestrian traffic? And pedestrians with trollies? Have a look at the Tournex. Read more
• Looking for something more transparent? The Crystal Tourniket would be a great option here. Read more
